Alphacool ES 1U - 7 x 40 / 2x XPX Pro 1U / Eisstation 40 DC-LT 3600rpm (11862)

The Alphacool ES 1U - 7 x 40 / 2x XPX Pro 1U / Eisstation 40 DC-LT 3600rpm is a prefilled water cooling kit for 1U server racks and workstations. It holds two Eisblock XPX Pro 1U CPU coolers, a full copper radiator for seven 40 mm fans, and an Eisstation 40 DC-LT reservoir with a DC-LT 3600 pump. All kits are made to order, and our Mod Team adjusts the tubing length to your server. With a single processor, the 7 x 40 set with one XPX Pro 1U is the same kit with one block.

Properties

CPU cooler

2x Eisblock XPX Pro 1U

Radiator

NexXxoS UT60 Full Copper X-Flow Hepta, 7 x 40 mm

Reservoir

Eisstation 40 DC-LT, integrated pump top

Pump

DC-LT 3600, 12V DC

Intel sockets

2011, 2011-3, 2066, 3647, 4189, 1700

AMD sockets

TR4, TR5, TRX40, sWRX8, SP3, SP6, AM4, AM5

Made to order

Let us help you keep your server rack cool: that is what these kits are for. Server racks differ in size and in the positioning of individual components, so every kit is individually adjusted for tubing length. Since no two builds match, our Mod Team can put together a server cooling kit that is specific to your setup, with the Enterprise Solution Sets from Alphacool as the base. Contact our support team at ModMyMods.com ([email protected]) to provide your tubing length, any special requests, and further information about your system. We'll do the work for you: get a kit, and we'll make it fit!

Notice: lead times are dependent on current product inventory. If a specific product that is part of this kit is not available, please be aware that it could take 30 days or more to complete your kit. The status of your order comes from our support team, who will keep you updated as it becomes available. Feel free to reach out to us at the same address for order updates, product availability, or specific build inquiries. We are here to help with any of it.

Cooling capacity

This setup can dissipate up to 490 W. Alphacool gives that figure for an ambient temperature of 30 °C and a fan with 12,000 rpm.

CPU cooler

Two Eisblock XPX Pro 1U water blocks come in this set, which Alphacool sells for dual socket boards. Alphacool lists the set for the Intel sockets 2011, 2011-3, 2066, 3647, 4189 and 1700 and for AMD TR4, TR5, TRX40, sWRX8, SP3, SP6, AM4 and AM5.

Radiator

The radiator is the NexXxoS UT60 Full Copper X-Flow 40mm Hepta. Alphacool relies on full copper radiators for these sets and says they offer almost twice the thermal capacity of aluminum radiators. As a result, by its account, a significantly better cooling performance is achieved, which counts due to the extreme packing density in server racks and workstations.

Reservoir

The Eisstation 40 DC-LT reservoir includes an integrated pump top. Alphacool's server reservoirs are specifically adapted to the respective height unit (1U, 2U, 3U, 4U) of the server racks, and this set is the 1U version. In addition, all reservoirs offer a variety of connection options, so the placement in the server can vary and be adapted according to your needs.

Hoses and Connectors

Alphacool leaves out the usual PVC hoses here: the tubing is TPV, which withstands higher heat than basic PVC tubing and resists buckling long term. The connections include special locking collars for the TPV tubing, which give them high-tensile strength. Compared to standard water cooling components, Alphacool calls that far safer, so you can feel safe and secure knowing all is secured from the start.

Pumps

The pump in this set is the DC-LT 3600 industrial pump, a 12V DC model. It and the DDC310 pump have been on the market for years, and their longevity is why we have chosen them for these kits.

Prefilled

Alphacool's Enterprise Solution Sets are always delivered prefilled, this one included. The set does not have to be assembled or filled: you only have to place the system in your server rack.

Fans

The radiator takes seven 40 mm fans. Ours are in the 40mm fans section.

In the box

• CPU Cooler: 2x Eisblock XPX Pro 1U
• Reservoir: Eisstation 40 DC-LT
• Radiator: NexXxoS UT60 Full Copper X-Flow 40mm Hepta (7x40mm)
• Pump: DC-LT 3600 - 12V DC - Pump - Industrial
