Details
A vertical connection terminal for the HEATKILLER V graphics card water blocks, made of POM (acetal) with two G1/4 threads. The Watercool HEATKILLER V Vertical VGA Terminal gives better connection options when the graphics card is installed standing.
Properties
- For
- HEATKILLER V VGA series
- Ports
- 2x G1/4 (DIN ISO 228-1), 25 mm apart
- Material
- POM, black
- Weight
- 50 g
For an upright card
With the card in a vertical mount, this terminal ensures the connecting threads sit where the tubes can reach them. The distance between the two is 25 mm. Watercool adds that this allows the cooler to be presented even better.
What you need to mount it
Each of the two ports takes one G1/4 fitting. For a card that lies flat, the standard HEATKILLER V VGA Terminal is the matching part, and the replacement O-rings for the V VGA series terminal come in a pair.
Compatibility
Watercool lists the whole series as compatible:
- HEATKILLER® V VGA series
Technical data
| Material | POM |
| Weight | 50 g |
| Connection | 2 x G1/4 inch (DIN ISO 228-1) |
| Thread distance | 25 mm |
In the box
- 1x HEATKILLER® VGA terminal
- 2x G1/4" screw plug
- mounting material
