Details
We have now expanded the high-quality radiators of the HEATKILLER RAD series to include 280 and 420mm versions. We rely on the popular slim format (S) with a height of 30mm. In addition to the optimized performance, the radiators are characterized by their compact dimensions and the high-quality workmanship typical of Watercool.
Finishing and quality control in Germany
In collaboration with a well-known manufacturer from Asia, we have succeeded in creating a powerful network radiator with a unique look. The cooling cores are manufactured strictly according to our specifications. The radiator housing is produced directly on site in Waren, which means that the finishing and quality control ultimately take place in Germany.
High cooling performance across the entire speed range
The aim of the development was to produce competitive radiators with a wide performance range. Accordingly, the HEATKILLER RAD shows very good cooling performance even with slowly rotating fans, which scales excellently as the speed increases. For maximum cooling performance, the HEATKILLER RAD can of course also be used in push/pull mode.
The best raw materials used
Only high quality raw materials are used as basis for the HEATKILLER RAD. The pre-chamber and the cooling channels are made of brass and the cooling fins are made of Copper. The side panels are laser-cut from 1mm thick steel plates or stainless steel and subsequently brushed or powder-coated in black or white, depending on the finish.The front sides are made of brushed stainless steel and significantly contribute to the exclusive look of our HEATKILLER RAD.
Easy integration into the cooling circuit
Integration into the circuit is done with two standard G1/4 inch threads. The connections required for this are not included in the scope of delivery. The manufactured thread passages ensure easy screwing in and high strength. The small width of just 120mm ensures maximum flexibility.
Technical data: HEATKILLER RAD-S 420
Dimensions: 460 x 140 x 30mm
Weight: 1.10Kg
Color: brushed stainless steel
Connections: 2 x G¼“ thread
Fan compatibility: up to 6 x 140mm fan (push-pull)
Radiator mounting: M3
Additional Information
| NE CA Item # | No |
|---|---|
| NE US Item # | No |
| Amazon ASIN | NA |
| Manufacturer | Watercool |
| Overall Dimensions | 460 x 140 x 30mm |
| Color | Stainless Steel |
| Radiator Type | 420mm |
| Radiator Thickness | 30mm |
| Fan Compatibility | 140mm |
| Fin Density | N/A |
| Screw Thread | M3 - 0.5 |
| Number of Ports | 2x G1/4 |
| Included | 1x Watercool HEATKILLER RAD 420-S Stainless Steel |
| Material | Brass |
