Details
The Aquacomputer Multiport Lid for ULTITUBE 200 Reservoir (34133) is a replacement lid for ULTITUBE 200 series reservoirs, made of acetal. It has two threaded G1/4 ports and an integrated pressure equalization membrane.
Properties
- For
- ULTITUBE 200 series reservoirs
- Material
- Acetal
- Ports
- Two G1/4 threads
- Membrane
- Pressure compensation, integrated
- Thread recess
- 25 mm diameter, 2.5 mm deep
How the membrane works
Gases can pass through the membrane while coolant is completely blocked from leaking, so it keeps equalizing the internal pressure of the loop with the ambient pressure. Aqua Computer says it effectively compensates the pressure fluctuations caused by temperature changes.
Ports and inlet tube
The two G1/4 ports in the lid take the coolant return, and two G1/4 sealing screws come with it. An acrylic glass tube of about 150 mm is enclosed as well. Once inserted in the lid, it helps prevent the noise and bubble formation that coolant flowing in would otherwise cause.
What the loop needs
The return line needs a G1/4 fitting for your tube size from our fittings section. A connector wider than the thread recess fits only on a suitable extension, for example from our extension fittings. For the shorter reservoirs there is the same lid for the ULTITUBE 150 and the ULTITUBE 100.
Notes
- The reservoir is not included in delivery.
- The connection threads sit in a recess 25 mm in diameter and 2.5 mm deep. Due to that recess, connectors with a larger outer diameter can only be installed with suitable extensions, which are not included.
In the box
- 1x Multiport lid for the ULTITUBE 200 reservoir, acetal, with pressure equalization membrane and G1/4 ports
- 2x G1/4 screw plugs
- 1x Acrylic glass tube, approx. 150 mm
