Details
The Stealkey Customs CubeTube Diagonal Port 60 mm is a short clear acrylic block with a milled channel inside that looks like a piece of hard tube. Its two G1/4" ports sit diagonally to each other: one on the front face near one end and one on the back face near the other end, so the tube runs connect from opposite sides of the block. It measures 60 x 31 x 16 mm and is CNC-milled and hand-assembled in Germany.
Properties
- Type
- Acrylic hard tube alternative (CubeTube)
- Length
- 60 mm
- Ports
- 2x G1/4", one front, one back (diagonal)
- Channel
- Like a 12 mm inside diameter hard tube
- Material
- Acrylic, EPDM seals
- Color
- Clear
A hard tube look without bending
Stealkey made the CubeTube as its first joint product with LiquidHaus. It has the character of a hard tube and can lift the look of a new or existing loop, without the work of cutting and bending acrylic tube. The channel inside matches a hard tube with a 12 mm inside diameter.
Diagonal ports
Unlike the straight CubeTubes, which have both ports on the front, this version has one port on the front face and one on the back face. The front port sits 44.5 mm and the back port 15.5 mm from the same end, so the two are 29 mm apart along the length. That lets one tube run come in from in front of the block and the other leave behind it, with an offset, in a very short part.
Made to keep the coolant moving
Stealkey says the channel is shaped so that coolant does not collect and stand in it, so the CubeTube does not disturb the flow through the loop.
Clear milled acrylic, sealed with EPDM
The milled surfaces are almost fully transparent, which gives the part its high-quality look. The halves are sealed with EPDM gaskets, which Stealkey says stay tight even under high loads.
Technical data
| Article number | SW10060 |
| Dimensions (L x W x D) | 60 x 31 x 16 mm |
| Ports | 2x G1/4", one front, one back (diagonal) |
| Port positions | Front 44.5 mm, back 15.5 mm from the same end |
| Channel | Like a 12 mm inside diameter hard tube |
| Material | Acrylic |
| Seals | EPDM |
| Color | Clear |
| Made in | Germany (CNC-milled and hand-assembled) |
Notes
- Stealkey makes the straight CubeTube in 60, 120, 140, 240, 280 and 360 mm lengths. This listing is the 60 mm version with diagonal ports.
- Clean acrylic parts with water only. Alcohol-based cleaners and solvents can cause stress cracks in acrylic, and Stealkey warns that incompatible coolants can damage acrylic parts as well.
In the box
- 1x Stealkey Customs CubeTube Diagonal Port 60mm - Acryl
