Details
The Aquacomputer Temperature Sensor Inline G1/4 for VISION is an inline coolant temperature sensor with two G1/4 inner threads, a cable of approx. 60 cm and a female miniature connector, for VISION Touch, the VISION connection terminals for kryographics and high flow NEXT.
Properties
- Threads
- 2x G1/4 inner thread
- Cable
- approx. 60 cm, female miniature connector
- Body material
- Nickel plated brass
- Cover material
- Delrin
Fit and technical details
The sensor sits in the tube run itself. A hose fitting screws into each of its two inner threads, and since those are standard G1/4, it can be combined with fittings for any tubing size.
What a run needs
Two G1/4 fittings for your tube, one per thread; they are in our fittings section. This sensor is equipped with a cable about 60 cm in length, and the connector goes to a temperature sensor input on one of the devices below.
Compatibility
Aquacomputer lists the sensor as compatible with these devices:
- VISION Touch (53235)
- VISION connection terminal for kryographics (23664, 23665, 23666, 23667)
- VISION RGBpx connection terminal for kryographics (23686, 23687)
- high flow NEXT (53293)
