Details
This triple power supply adapter cable starts three ATX power supplies together with one motherboard. Its main part is a 24-pin extension cable: plug it between the 24-pin cable of the main power supply and the 24-pin socket of the motherboard. Each of the two extra leads ends in a 24-pin connector that plugs into the 24-pin cable of each additional power supply, so all three supplies switch on and off together with the motherboard.
Properties
- Type
- Triple power supply adapter cable
- Main part
- 24-pin ATX extension, 30 cm
- Extra leads
- 2x 24-pin, 30 cm each
- Power supplies
- 3
- Cable color
- Black
- Pieces in the pack
- 1
Power on three supplies at once
When the motherboard turns on, the main power supply starts as usual and the adapter passes the start signal on to the additional supply through the extra lead, so you never have to switch a second supply by hand or bridge pins. When the PC shuts down, all supplies turn off together.
For builds that need a lot of power
One power supply is not always enough. The adapter is made for crypto mining rigs, render and test machines and any other build that draws more power than a single supply can give: the additional supplies power graphics cards, risers, pumps or drives through their own cables.
How it is wired
The main part carries all 24 lines like a normal 24-pin extension, so the motherboard is powered by the main supply exactly as before. Each extra lead has only two thin wires, enough for the start signal, so it stays slim and easy to route to a supply in another part of the case or rig.
Technical data
| Part number | MOD-0211 |
| Type | Triple power supply adapter cable |
| Main part | 24-pin ATX extension, male to female, 30 cm |
| Extra leads | 2x 24-pin connector on two wires, 30 cm each |
| Power supplies started together | 3 |
| Cable color | Black |
Notes
- Switch all power supplies off at their rear switches before you connect or remove the adapter.
- Plug the extra leads only into the 24-pin cable of an additional power supply, never into a motherboard.
- ModMyMods makes this adapter for two power supplies (MOD-0210) and three power supplies (MOD-0211). This listing is the triple version.
In the box
- 1x ModMyMods 24-Pin Triple Power Supply Adapter Cable - 30cm - Black
